The BCM 9900-DI150_PB_Q is a multifunctional dimmer, fader and driver for 12, 24 and 48 VDC lighting installations. The module provides precise brightness control and is suitable for various onboard lighting systems.
The lighting can be controlled using a push button, a 0-10 V signal, a 1-10 V signal or a potentiometer. The dimmer supports complete switch-off and has a minimum brightness level of 0.1 percent. When operated by a push button, the minimum brightness level is 1 percent.
The PWM frequency can be set to 300, 600 or 1200 Hz. A linear, quadratic or exponential dimming curve can also be selected. The soft-start and soft-stop function allows the lighting to switch on and off gradually.
The module has a typical efficiency of more than 95 percent, is suitable for R, L and C loads and can be used within an extended temperature range. The product is fully function tested and supplied with a five-year manufacturer’s warranty.
Before installation, verify that the connected lighting, load and supply voltage are compatible with this module. This product is available on request only.
